COLD ROLLED FULL HARD SHEET COIL:-

Cold Rolled are manufactured at the highly advanced cold rollig mill and can be used in a In industrial goods such a automobiles components , prescision tubes and consumer durables , in the manufacture of bodies of vehicle as varied as automobles and railway coaches , for the production of heavy machierny like earthmoving and meateial-handling equpiment, Specially suited for panel application in refrigerated bodies and washing machines, In Cycle parts, office equipments and furniture and for basic items such as galvanised sheets, tin plates, drums and barrels.

Specification

As per JIS G3  141 SPCC-1B/ Equivalent

Thickness

0.11 mm to 0.700  mm

Width

Upto 1020 mm

Coil Inner Diameter

508  mm  to 610 mm

Packing

 Seaworthy Export Packing

Coil Weight

10  M.T. Maxi.

Materail Supplier

Coils  or Sheet

Application

Suitable for galvanising

COLD ROLLED NON- ELECTRICAL STEEL COIL:-

It is used for the cores fo high efficiency transformers, electric motor and generator. It is also used when efficiency is less important or when there is insufficient space to correctly orient componentsto take advantage of the anisotropic properties of gain-oriented electrical steel. Non-Oriented Electrical Steel usually has a silicon level 2% to 3.5% and has similar magnetic properties. It is less expensive and is used in application where the directions of megnetic flux is changing. Such as eletric motor and generator.

Specification

50WW1300, 50WW800 & 50WW600

Thickness

0.50 MM

Width

1000 mm to 1200  mm

Coil Inner Diameter

508  mm  +/-

Packing

 Seaworthy Export Packing

Coil Weight

4  M.T.  to 8 M.T..

Materail Supplier

Coils  or Sheet

Application

Suitable for galvanising

COLD ROLLED CLOSED ANNEALED COIL :-

It is used for drums, barrles, containers, bicyles parts, consumer durables, auto mobiles parts, radiators, pannel engg. Fabrication , bearing cages fans, automobiles inner cover and outer pannel.

Specification

JIS-G-3141-1996 SPCC-SD/SB, SPCE-SD/SB,SPCEN-SD/SB CR-1,CR-2,CR-3 & CR-4

Thickness

UPTO 2.50 mm

Width

1250  mm  max

Coil Inner Diameter

508  mm  +/-

Packing

 Seaworthy Export Packing

Coil Weight

10  M.T.  Max

Materail Supplier

Coils  or Sheet

Application

Suitable for galvanising

TIN PLATE ( ELECTROLYTE TIN PLATE ):-

By far the largest application of tinplate is in packaging and it is ideally suited for this purpose, by virtue of it being non-toxic, light in weight, strong, corrosion resistant and easily formed, soldered and welded; it also provides an excellent printing surface. The tin coating has a low melting point, possesses lubricant qualities and imparts a good appearance. Cans made from tinplate are easy to handle, dispose and store. Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, powdered, polishes, waxes, chemicals and many other products. Aerosol containers and caps and closures are also made from tinplate.

Standard

GB/T 2520-2000, JIS G3303-2002 and DIN EN 10203-1991

Thickness

0.18 mm to 0.50  mm

Width

260 mm to 980 mm

Coil Inner Diameter

ID 420 mm or 508 mm

Packing

 Anti-rust paper, corner protected, sheet or coils according customer request

Temper Grade

 T2 , T3 and T4

Tin Coating

Ordinary 2.8 or 2.8g and 5.6 or 5.6g, We can arrange to customer request

Application

Paint , chemical and other usage can make battery, electric cable and other industries.
